EDGAR B SPEER

No repairs or alterations affecting the safety of the vessel with regard to the hull, machinery, or equipment, shall be made without the knowledge of the Officer in Charge, Marine Inspection. Isolate leaking hydraulic fluid cooler on the conveyor belt tensioning motor to prevent contamination of water in the aft peak tank and ensure aft peak tank is free of oil prior to using aft peak tank for cooling water.

See "Speer Ballast Tank Survey Notes" document.

Vessel Captain reported that a crack was discovered in the starboard main engine (SME) block, rendering it inoperable. The extent of the damage is unknown at this time pending further investigation. Vessel is authorized to operate under reduced propulsion with the ship's port main engine (PME) until 07 JUL 2022 IAW USCG D9's "GUIDANCE FOR VESSELS OPERATING WITH REDUCED PROPULSION". Vessel is to make permanent repairs to the SME, and demonstrate proper operation. Repairs must be satisfactorily completed prior to resuming cargo operations (at the end of this 30-day period allowing operation under reduced propulsion). Vessel owner/operator to keep MSU Duluth notified of any changes in the vessel's operational status, and/or maneuvering characteristics. Use of assist tugs in restricted waters, as outlined by the company rep., has been approved by all applicable OCMI zones. Examination of repairs shall be verified by either a Class Surveyor or USCG Marine Inspector.

The material, design, construction, workmanship and arrangement of main propulsion machinery and of each auxiliary, directly connected to the engine and supplied as such, must be at least equivalent to the standards established by ABS Steel Vessel Rules. Vessel experienced equipment failure rendering the starboard main diesel engine inoperative. Vessel is to make permanent repairs to the starboard main diesel engine, in accordance with ABS Steel Vessel Rules. Permanent repairs to be completed to the satisfaction of either Class or Coast Guard Marine Inspectors.

Heat sensor above prime mover on #1 SSDG not operational. Manning levels on COI are contingent on proper operation of automated monitoring systems, including fire detection. Make permanent repairs to designated heat sensor.

Port main engine has faulty overspeed sensor causing the engine to shut down. Replace sensor and test engine/sensor to the satisfaction of Coast Guard Marine Inspector.

Yielding rod on Port main engine was sticking causeing the rpms to hunt and not settle on the given input. CE was able to fabricating replacement part within 2 hours and make permanent repair.

Make repairs and demonstrate proper operation of ship's #3 service generator.

Voltage regulator for newly installed SSG (#1) is not operating properly, resulting in an inablility for the #1 SSG to be paralleled with the other 3 operational SSGs. Troubleshoot cause for voltage regulation issue and make repairs upon arrival in Port of Duluth, MN.

Submit plans for review and approval to add sufficient charging capacity and battery source for electronic controls of all ship service generators.

#2 Ship's service generator tripped while vsl was backing out of slip. Generator was brought back online and load tested but reason for failure could not be identified. Service technician will attend at next port of call.

Great Lakes Fleet, Inc. has elected to voluntarily deposit the Certificate of Inspection (COI) for the M/V EDGAR B. SPEER to Marine Safety Unit Duluth, and apply for temporary lay-up status due to low economic demand. The COI will be returned to Great Lakes Fleet, Inc. upon request without lapse with the caveat that all inspection requirements under SIP are satisfied prior to sailing.

During the course of the annual SIP Audit significant program element breakdowns were identified compelling remedial action by the coast guard in way of requiring a follow up audit to ensure system failures are identified and corrected. Make vessel available to the SIP agent for a follow on audit prior to the end of the 2008 shiping season.

Fire control plan requires revision to reflect location of response gear.

Port #4 Ballast tank had small & 7" crack 8ft aft of forward bulkhead at second stiffener.

Install blanks on exposed connections on electrical panel L-9. Submit SIP Correction report to [name withheld].

Life boat engine, failed to start during routine test. Fuel lift pump or injector pump failed.

#6 ballast tank Starboard side aft, 12"-18" crack at welded seam. Forward of starboard main engine

Make repairs to fractured gussets in the Port #3 void, frame 7, 8, 9, port void #5 frames 3 and 4 and stbd void #5 frame 5, 6, and 13. Cracks are at the base of the Gussets between the cargo slope and the ballast tank bulkheads.

Conduct permanent repairs to #1 web frame, in # 6 stbd ballast tank,between side longs #2-6 & web frame #2 IVO sidelong #2. Repairs to consist of inserting affected areas, temporarily gouged & re-welded. Permanent repairs to be completed to the satisfaction of the attending C.G. Marine Inspector.

Conduct permanent repairs to the 12th deck beam (from aft) inboard, in the #3 stbd ballast tank. Repairs to consist of inserting affected area. Temp repairs authorized to consist of drill stop, gouge and re-weld. Permanent repairs to be completed to the satisfaction of the attending C.G. MI

Starboard side, inboard group 1 pump, had a low pressure switch failure. Hydraulic fluid did leak from the switch, contained in containment.

Damage to starboard #2 ballast tank.

#1 ships generator burned out durning unloading ops in [name withheld].

#1 Ships service generator burned out durning unloading operations in [name withheld]. LEGACY COMPONENT DESC: Generator

Make permanent repair to vertical crack in #6 port FWBTat frame 114, appr. 4" in length, located at the 25' draft level. LEGACY COMPONENT DESC: Side Shell

Make permanent repairs to 4" hull fracture #6 port ballast tank.

Label fuel oil shutoff valves in ECR head.

Block and brace emergency power battery bank in emergency generator room

Proceed directly to Sturgeon Bay, WI to effect permanent repairs to starboard rudder. LEGACY COMPONENT DESC: Rudder

Submit design calculations for rudder shafts per ABS Rules and 46 CFR 58.25-10. Since the dimensions of the actual port and starboard shafts differ, separate calculations must be submitted for each. Include a third set of calculations for the shaft that failed. LEGACY COMPONENT DESC: Rudder Stock

Renew Starboard Rudder post and rudder assembly, and conduct operational test as required by attending Marine Inspector IAW 46CFR58.25-10. LEGACY COMPONENT DESC: Rudder

Provide Non-Destructive test results of port rudder shaft to ensure no fractures due to design calculations showing that stresses induced exceed yield values for rudder shaft.

REPAIR LOCKING HEAD SLIDE ASSEMBLY ON PORT ANCHOR WINDLASS. ENSURE PORT ANCHOR RAISES UNDER POWER PROPERLY. LEGACY COMPONENT DESC: Clutch

COMPLETE REPAIRS AS INDICATED IN ABS CHICAGO REPORT #CH342513 TO THE SATISFACTION OF ATTENDING MARINE INSPECTOR. STEEL CERTS AND A SCOPE OF WORK PLAN SHALL BE SUBMITTED TO [name withheld]. CONDUCT NDE OF AFFECTED REPAIRS TO COLLISION BULKHEAD TO SATISFACTION OF [name withheld]; ENSURE WORKMANS

Correct 50 item steel repair list dated 21JAN02 prior to undocking vessel.

Make permanent repairs to port and starboard bilge brackets in way of sea chest frame 113 3/4.

Make permanent repair to bulkhead port side in way of sea chest frame 113.

Escape hatch from E/R to spar deck is inopereble/ wil not open._x001C_ _x001C_ _x001C_ _x001C_

Fire main at midship port spar deck has hole.

Repair watertight door indicating light on stbd outboard air intake.

Prove current hydrostatic test dates for all SCBA tanks.

Conduct lifeboat drill and test of motor lifeboat operation in water to satisfaction of an attending marine inspector.

EOT wrong direction alarm not working.

Repair bridge fire detection alarm.

TEST MECHANICAL OVERSPEED TRIP ON STBD. MAIN ENGINE. NOTIFY THIS OFFICE BY LETTER WHEN COMPLETED. COMPLETE NO LATER THAN APRIL 10, 1995.

AT NEXT PORT OF CALL BUT NO LATER THAN APRIL 06, 1995, CONDUCT ABANDON SHIPDRILL, LOWER LIFE BOAT AND OPERATE ENGINE. THE PRESENCE OF A COAST GUARD MARINE INSPECTOR IS NOT REQD FOR THIS DRILL. NOTIFY THIS OFFICE BY LETTER WHEN DRILL IS COMPLETE.

Effect permanent repairs to indented area on stbd side in #1 ballast tank at 32' draft mark, 150' aft of stem. Effect repairs to welds on various frames.

ARRANGE FOR CG INSPECTION OF PERMANENT REPAIRS TO WATERTUBE ON AFTER AUXILIARY BOILER.

LIFE BOAT NOT EXERCISED DUE TO ICE CONDITIONS IN DULUTH HARBOR. VSL ISSUED REQ D-1 TO EXERCISE LIFEBOAT BY 05 APR 94.

TEST MECHANICAL OVERSPEED TRIP PORT MAIN ENGINE NO LATER THAN 12APR94. THISREQT MAY BE CLEARED BY LETTER FROM THE [name withheld] DULUTH STATING ENGINE RATED SPEED AND RPM AT WHICH THE OVERSPEED TRIP OPERATED.

HYDROTEST FORWARD AUXILIARY BOILER NO LATER THAN 30 NOVEMBER 1995. HYDROTEST INTERVAL EXTENDED IN ACCORDANCE WITH MVI POLICY LETTER 11-93 TO COINCIDE WITH NEXT HULL EXAM.

CONDUCT INTERNAL EXAM OF ALL PRESSURE VESSELS (AIR RECEIVERS) NO LATER THAN30NOV95. EXAM INTERVAL EXTENDED IAW MVI POLICY LETTER 11-93.

HYDROTEST AFT AUXILIARY BOILER NO LATER THAN 30NOV95. HYDROSTATIC TEST INTERVAL EXTENDED UNDER MVI POLICY LETTER 11-93 TO CORRESPOND TO NEXT CREDIT DRYDOCKING.

TEST AUXILIARY ELECTRONIC OVERSPEED TRIPS BOTH MAIN ENGINES.

MAKE LOW L.O. PRESSURE SHUTDOWN ON EMERG. DIESEL GENERATOR OPERABLE.

REPAIR NO. 1 MDE FUEL OIL RETURN CUT OUT VALVE REACH ROD.

HOLD ABANDON SHIP DRILL, LOWER TO WATER AND OPERATE LIFEBOAT. THE PRESENCEOF A MARINE INSP. IS NOT REQ.

MAKE LOW L.O. PRESSURE SHUTDOWN ON EMERG. DIESEL GENERATOR OPERABLE.

INSTALL USCG APPROVED HOSES ON EMERG. DIESEL GEN. FUEL OIL SYSTEM

TEST AUXILIARY ELECTRONIC OVER SPEED TRIPS BOTH MAIN ENGINES.

REPAIR LIFEBOAT ENGINE AND TEST SAME IN THE PRESENCE OF A MARINE INSPECTOR PRIOR TO DEPARTING NEXT PORT OF CALL (CONNEAULT, OH) BUT NO LATER THAN 12OCT92.

OVERSPEED PORT AND STBD MAIN DIESEL ENGINES WHEN SUFFICIENT HOURS HAVE BEENACCUMULATED TO SEAT THE RINGS. NOTIFY MILMS AND DULMS IN WRITING WHEN THISREQUIREMENT HAS BEEN SATISIFIED.

SUBMIT REVISED TEST AUTOMATION TEST PROCEDURES FOR CONSUMAT INCINERATOR TO [name withheld] NO LATER THAN 19APR91.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

AFTER FIRST TRIP BUT NO LATER THAN 19APR91, REPAIR LEAK IN PORT NO. 3 VOID AT CONNECTION OF SLOPE TO OUTBOARD BULKHEAD AT FRAME 7 FROM FORWARD AND ANYOTHER LEAKS FOUND IN WAY OF NO. 3 CARGO HOLD.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

CONDUCT ANNUAL INSPECTION OF ALL LOWER RUB RAIL INTERRUPTIONS ENDS, INSERT PLATES AND LONGITUDINAL CLIPS.

CONDUCT ANNUAL INSPECTION OF REPAIRED DEEP WEB BRACKET TO MAIN DECK BEAM AND REPAIRED DEEP WEB BRACKET TO FLOOR CONNECTION IN ALL BALLAST TANKS, INBOARD AND OUTBOARD. ALL CONNECTIONS REPAIRED THIS DATE ARE PAINTED YELLOW

CONDUCT ANNUAL INSPECTION OF REPAIRED DEEP WEB BRACKET TO FLOOR CONNECTIONS IN #1-5, PORT AND STBD VOID TANKS. ALL CONNECTIONS REPAIRED THIS DATE AREPAINTED YELLOW.

AT THE NEXT DRYDOCKING FOR ANY REASON COMPLETE PERMANENT REPAIRS THROUGHOUTTHE VESSEL TO THE FLOORS IN WAY OF THE BRACKET CONNECTION TO THE WEB FRAMESOUTBOARD. THE EXTENT OF THE REPAIRS WILL BE AS DEEMED NECESSARY BY THE COGNIZANT [name withheld] IN #2 P/S ARE CONSIDERED TEMPORARY ONLY.

SURVEY & MAKE PERMANENT REPAIRS AS DEEMED NECESSARY BY THE COGNIZANT CG OCMI TO THE DAMAGES IN THE HULL PLATING & INTERNALS IN #2 STBD BALLAST TANKIN WAY OF THE TURN OF THE BILGE, 1ST & 2ND LONGS OUTBOARD, AND THE LONG- ITUDINAL BULKHEAD & 1ST LONG INBOARD, AT THE FIRST DRYDOCKING FOR ANY REASN

SUBMIT TO THE CG MARINE SAFETY CENTER VIA ABS,PROPOSALS TO EFFECT PERMANENTREPAIRS TO THE OUTBOARD CONNECTION OF THE WEB FRAME AND FLOORS. THIS REQUIREMENT SPECIFICALLY ADDRESSES #2 P/S BALLAST TANKS, BUT MUST BE APPLICABLE TO ALL TANKS. THESE APPVD PLANS SHALL BE UTILIZED IN THE COMPLETION OF H-3.

PROVE OPERATION OF THE PORT AND STBD MAIN DIESEL ENGINES OVERSPEED TRIPS TO THE SATISFACTION OF THE COGNIZANT OCMI AND ATTENDING US COAST GUARD INSPECTOR.

PRIOR TO 31 JULY 1990, BUT IN NO CASE LATER THAN THE NEXT DRYDOCKING FOR ANY REASON, MAKE PERMANENT REPAIRS TO THE HULL AND INTERNAL FRAMING IN WAY OF THE DAMAGES IN #4,#5 AND #6 STBD BALLAST TANKS. ALL REPAIRS EFFECTED ARECONSIDERED TEMPORARY. REPAIRS SHALL BE TO THE SAT. OF THE COGNIZANT OCMI.

TEST OPERATION OF OVERSPEED TRIP ON STBD MAIN ENGINE TO THE SATISFACTION OFTHE ATTENDING USCG INSPECTOR AND COGNIZANT OCMI PRIOR TO 13 APR 89.

SUBMIT AND OBTAIN CG APPROVAL OF DRAWINGS DEPICTING ACTUAL FIXED ENGINE ROOM CO2 SYSTEM INSTALLATION

E-4 CONDUCT HYDROSTATIC TEST AT NOT LESS THAN 150 PSI ON REPAIRED SECTION OF FUEL INLET HEADER ON INBOARD SIDE OF PORT MAIN ENGINE. THIS TEST MUST BE ACCOMPLISHED IN THE PRESENCE OF A USCG MARINE INSPECTOR NOT LATER THAN 21 APRIL 1988.

UPDATE AUTOMATION PROCEDURES, ALL PUMP STANDBY TESTS ARE IN ERROR.

MAKE FORMAL PROPOSALS TO THE CORRECTION OF CO2 SYSTEM DESIGN.

OVERSPEED BOTH MAIN DIESEL ENGINES.

DETERMINE THE CAUSE OF THE OIL LEAK AT THE PORT STERN AND MAKE REPAIRS.

MAKE NECESSARY REPAIRS TOPORT DECK FIREMAIN LINE AT HATCH #14 TO STOP LEAKING.

CHANGE THE FUEL OIL IN THE MOTOR LIFEBOAT.

PROVIDE OIL TRANSFER PROCEDURES AS REQUIRED BY 33 CODE OF FEDERAL REGULATIONS, PART 155.720, THE CONTENTS TO COMPLY WITH 33 CFR 155.750.

WITHIN THIRTY DAYS, HAVE FIRE CONTROL PLAN UPDATED TO REFLECT ACTUAL FIRE- FIGHTING EQUIPMENT ON BOARD AND ITS LOCATION. NOTIFY THIS OFFICE WHEN THIS REQUIREMENT IS COMPLETE.

WITHIN FIFTEEN (15) DAYS, TEST THE OVERSPEED TRIPS ON BOTH MAIN PROPULSION DIESEL ENGINES IN THE PRESENCE OF A COAST GUARD MARINE INSPECTOR.

PROCEED TO SHIPYARD IN STURGEON BAY, WISCONSIN TO REMOVE THE STARBOARD BROKEN RUDDER SHAFT AND INSTALL NEW REPLACEMENT SHAFT AND RUDDER.

REPAIR AND TEST GENERAL ALARM ROTATING BEACON IN STARBOARD ENGINE ROOM TO THE SATISFACTION OF THE COGNIZANT OCMI PRIOR TO 15 APRIL 1985.
