S-2011

No repairs or alterations affecting the safety of the vessel with regard to the hull, machinery, or equipment shall be made without the knowledge of the OCMI. Found a temporary repair with splash zone on the turn from the head log to the main deck of the forward center rake. Submit repair plan for review/approval prior to making permanent repairs.

Side lights each showing an unbroken light over an arc of the horizon of 112.5 degrees and so fixed as to show the light from right ahead to 22.5 degrees abaft the beam on its respective side. Port and starboard side light's post mount is bent and not displaying the proper angle of view.

The ring, lines, and letters shall be painted in white or yellow on a dark ground or in black on a light ground. The load line plimsoll mark and deck line is unreadable.

Replace missing hardware for manhole covers and sheered off bolt on multiple multiple manhole covers and repair aft most pad eye on starboard main deck in way of stbd aft rake.

Suspected bottom plating wastage in forward port rake. Remove water and gage bottom plating in way of ladder. Submit gage report to USCG for review and effect repairs if required to the satisfaction of the atending MI. Updated 13MAY2022: PDATE/13MAY2022: Approval granted by Sector Guam's CID to clad weld pits gaged over 25% on bottom hull plating in forward center rake by no later than 01JUN2022, to the satisfaction of the attending USCG Marine Inspector (MI). In addition, space must be certified gas free by a Marine Chemist for USCG MI entry for further inspection. Note: bottom hull plating in forward center rake is subject to further repairs.

Port side deck line with wastage. Repair port side deck line to as original.

Replace wasted upper flat bar attached to ladder with new in port aft center rake at next dry dock or ISE, whichever comes sooner.

The ring, lines and letters shall be painted in white or yellow on a dark ground or in black on a light ground. The marks shall be plainly visible. Paint have rubbed off on port and starboard hull markings. Repaint port and starboard load line, draft marks, and freeboard.

Prove operation of navigational lights and repaint screens flat black.

Replace emergency towline shackles (3 x 50 ton) with new. Shackles are weathered and heavily rusted; no maintenance records provided to prove when last replaced.

Based on log book, found that vessel has been operating with an invalid IOPP Certificate since 28 DEC 2018.

Made repairs to the hull without the knowledge of the OCMI.

Annual/Periodic inspection not conducted IAW with allowable window.

Annual survey not conducted / lapsed.

Unapproved/unauthorized davit was installed on the stern of barge.

Load Line not marked IAW ILLC certificate.

Excess water observed in forward voids. Suspected breach of hull.

COI was not onboard.

Vessel not operating IAW with ILLC certificate.

Vessel not watertight / not in compliance with USCG Stability Letter & ILLC certificate.

PROVIDE UNDERWATER SURVEY RESULTS, VOYAGE PLAN, AND DAMAGE STABILITY CALCULATIONS, SPECIFICALLY IN THE EVENT OF FLOODING OF DAMAGED AREAS TO COTP GUAM FOR REVIEW AND/OR APPROVAL. PRIOR TO DEPARTURE FROM WAKE ISLAND

Install hand rails as required. All hand rails removed on both Port and STBD sides of barge.

Freshen Paint on Load Line marks both Port & Starboard sides.

Open Cleat on bow stbd side wasted and needs repair. Repair/replace as needed.

Repair wasted rub rail as needed on bow stbd side. Rub rail is wasted all the way thru in that area.

Repair/replace missing lag bolt and nuts as needed on hatch cover man holes.

Repair as needed wasted rub rail on stern stbd side. Rub rail wasted all the way thru in that area.

Take random gauging of deck on barge 5 feet aft of midship portside from edge inboard 15-18 feet. Approx 4-8 shots to compare against original scantlings.

S-3 void finish weld in overhead, S-1 void finish circle plate repair in the overhead, Port fwd peak frame seperated from hull needs repair, repair fractured stbd pad eye for towing bridle.

Load line over due fro Class.

Claa cert over due on 20 Jan 09

Make inner bottoms ready for inspection, gas free, and man holes open. Internal inspection due 11 Jan 09 on the vessels COI.

Barge has not completed a credit dry dock by an attending USCG Marine Inspector. Vessel may not conduct any commercial operations until cleared by completing a credit dry dock.

Make permanent repairs to Nav light including the replacement of all photocell.

Forward port wing tank. Crop and renew #3 and #4 bottom longitudinal. LEGACY COMPONENT DESC: #3 & #4 bottom longitudinal

#1 port tank. Crop and renew #1 web frame in way of stbd bulkhead. LEGACY COMPONENT DESC: #1 web frame

#3 port tank. Crop and renew #2 side shell web frame. LEGACY COMPONENT DESC: #2 web frame

Aft port wing tank. Crop and renew gusset in way of bottom of ladder. LEGACY COMPONENT DESC: Gusset

# 2 stbd tank. Aft bulkhead holed in way of deck stbd side LEGACY COMPONENT DESC: Aft bulkhead

Renew deteriorated scuttle access covers.

Install retroreflective material on ring buoy.

Renew deteriorated navigation light wiring.

Renew deteriorated port battery box cover.

Renew deteriorated mooring bits.

Renew port forward navigation light bracket.

Reinstall fire extinguishing system following appropriate servicing and power supply units prior to carriage of freight or other materials. Servicing of extinguishing system to be in accordance with NFPA Standards and 46 CFR Subchapter I.

Recharge navigation light batteries prior to carriage of any freight or other materials.

Permanently mount navigation light electrical switches.

Sounding pipe in stbd forward wing tank is deteriorated and requires renewal. Permanent repair to be made not later than 04APR98 after a repairproposal is submitted to the USCG Office conducting oversite.

Guaging of lower aft rake collision bulkhead to determine % of wastage is to be conducted NLT 04APR98. Guaging to be conducted at most wasted areas in lower 18 inches of bulkhead at intervals not to exceed 18 inches. If more than 25% plate thickness missing, crop & renew to sound plate.

Collision bulkhead in way of the port ladder in the forward center bow rakeis deteriorated & requires renewal. Est. size of required insert is 6.5 feet x 2.0 feet (H x W). Permanent repair to be made not later than 04APR98after a repair proposal is submitted to the USCG Office conducting oversite

Holed areas exist in the longitudinal bulkhead btwn the stbd forward wing tank & the center bow rake compartment. Est. size of largest insert is 12 feet x 3.5 feet (H x W) w/two additional smaller inserts required. Perman-ent repair to be made not later than 04APR98 after repair proposal to USCG.

Hull plating in No. 1 stbd tank on stbd side approximately 4 feet aft of the forward bulkhead approx. 0.5 feet below the overhead is cracked. Crackextends approx. 1 foot. Permanent repairs to be made not later than 04APR98after a repair proposal is submitted to the USCG Office conducting oversite

Sounding pipe in port forward wing tank is deteriorated and requires renewal. Permanent repair to be made not later than 04APR98 after a repairproposal is submitted to the USCG Office conducting oversite.

PROVIDE APPROVED "MARINE TYPE" PORTABLE FIRE EXTINGUISHER IN FUEL TANK/GENERATOR CONTAINER.

Repair the installed CO2 system located in the fuel tank/generator container.

BATTERY BOXES must be lined or replaced with boxes of approved material. This includes one on the bow and two in the generator room.

Provide for inspection all permanent repairs to Port & Stbd side frames & longitudinals and hull inserts required to be renewed by CG Inspector.

PROVIDE NAVIGATION LIGHT BATTERY BOXES WITH FIBERGLASS/LEAD LINING IAW 46 CFR 111.15-5(g).

MAKE CONTAINERIZED GENERATOR SET AVAILABLE FOR INSPECTION. INSPECTION SHALL INCLUDE BUT NOT LIMITED TO; GENERATOR TRIPS, ELECTRICAL SYSTEM, AND FIREFIGHTING SYSTEM.

PROVIDE MSO HONOLULU A CERTIFIED COPY OF THE VESSEL'S STABILITY LETTER.

PROVIDE MSO HONOLULU WITH A COPY OF THE DOCUMENTATION CERTIFICATE.
