ROBERT C LANIER

Each pump shall be capable of delivering water simultaneously from the two highest outlets at a pilot tube pressure of approximately 50psi During the inspection both the fire pump and emergency fire pump would not maintain 50 psi. Once satisfactory repairs are made provide class report to MSU Texas City Domestic Inspections E-Mail: TXCDOM@uscg 46 CFR 76.10-5c action code 701a

A survey, either general of partial, according to the circumstances, shall be made every time an accident occurs or a defect is discovered which affects the safety of the vessel or the efficacy or completeness of its lifesaving appliances, fire-fighting or other equipment, or whenever any important repairs or renewals are made. The survey shall be such as to insure that the necessary repairs or renewals have been effectively made, that the material and the workmanship of such repairs or renewals are in all respects satisfactory, and that the vessel complies in all respects with the regulations in this sub chapter. Vessel ran aground while transiting near Bolivar Ferry Terminal. A class (ABS) report attesting to the satisfactory structural integrity of the vessel is required. In addition, A class (ABS) report attesting to the satisfactory condition of the vessel running gear is required. Send all reports to [email withheld].

If a pipe, scuper, or electric cable passes through a main transverse watertight bulkhead, the opening through which it passes must be water tight. Marine Inspector found MCT installed improperly on the watertight bulkhead of A-End Engine Room. Provide evidence of proper installation. 16 AC code issued.

All portable fire extinguishers and semi-portable fire extinguishing systems must be maintained in accordance with NFPA 10, chapter 7. The CO2 portable fire extinguisher on the B-End Starboard side up forward has many cracks along the hose and needs to be replaced.. 46 CFR 71.25-20(a)(1)

Electric equipment must be arranged, as far as practicable, to prevent mechanical damage to the equipment from the accumulation of dust, oil vapors, steam, or dripping liquids. Electrical distribution and junction boxes in the center area of the engine room are excessively corroded having liquid dripping from a leaking pipe flange joint connection approximately 20ft. above, inside the exhaust trunk which needs to be repaired at the next dry dock (due 28OCT2024). The electrical box enclosures must be repaired or replaced as needed to ensure proper protection of internal connections. 46 CFR 111.01-3(a)

Metals in contact with each other must be either galvanically compatible or insulated with suitable non-porous materials. Provisions must also be made to prevent loosening or tightening resulting from differences of thermal expansion, freezing, buckling of parts, galvanic corrosion, or other incompatibilities. The rescue boat release mechanism has a shackle with a broken coder pin due to corrosion and the shackle bolt is completely corroded, which needs to be replaced with a bolt and coder pin of acceptable compatible material. 46 CFR 160.170-7(b)(5)

The material, design, construction, workmanship and arrangement of the main propulsion machinery and of each auxiliary, directly connected to the engine and supplied as such, must be atleast equivalent to the standards established by the ABS Steel Vessel Rules. TXDOT reported an overspeed on the "B" end main engine. Vessel is to troubleshoot and affect repairs, provide technicians report and ABS report attesting to satisfactory repairs to USCG at [email withheld].

Each vessel under 12 meters must display an all-around white light. Rescue boat all-around white light was not working properly when tested. Replace light within 14 days.

Electric installations on vessels must ensure: Protection of passengers, crew, other persons, and the vessel from electrical hazards. Vessel is experiencing electrical issues causing the (Voith) propulsion system alarms to activate in the navigation bridge. Repairs are to be completed prior to carrying passengers and to the satisfaction of a CG Marine Inspector.

Electric installations on vessels must ensure: Protection of passengers, crew, other persons, and the vessel from electrical hazards. Vessel is experiencing electrical issues causing the (Voith) propulsion system alarms to activate in the navigation bridge. Repairs are to be completed prior to carrying passengers and to the satisfaction of a CG Marine Inspector. 46 CFR 111.01(a)(2)

Complete but simple instructions for the operation of the systems must be located in a conspicuous place at or near all pull boxes, stop valve controls and in the CO2 cylinder storage room. On systems in which the CO2 cylinders are not within the protected space, these instructions must also include a schematic diagram of the system and instructions detailing alternate methods of discharging the system should the manual release or stop valve controls fail to operate. Marine Inspector observed several labels were missing on parts of both, the Engine Room and Emergency Generator Room CO2 systems, and therefore not in accordance with the respective instructions and schematic diagrams. Additionally, Step 2 and Step 3 on the instructions for the Engine Room CO2 pull box station did not align with each pull handle labeled Step 1 and Step 2.

It shall be the duty of the owner, master, or person in charge to see that the vessel's firefighting equipment is at all times ready for use and that all such equipment required by the regulations in this subchapter is provided, maintained, and replaced as indicated. Marine Inspector observed posted instructions located in the engine room were for an older and different type of the semi-portable fire extinguisher than was present.

The material, design, construction, workmanship, and arrangement of the main propulsion machinery and of each auxiliary, directly connected to the engine and supplied as such, must be at least equivalent to the standards established by the ABS Steel Vessel Rules (46 CFR 58.03-1) While transiting, vessel reported a reduction in RPMs while utilizing System 1 for their propulsion arrangement. Prior to the carriage of passengers/cargo,make repairs and provide tech report to the satisfaction of the OCMI.

Every vessel subject to Part III of Title III of the Communications Act must have a detailed inspection of the radio installation by an FCC-licensed technician. If the ship passes the inspection, the technician will issue a Communications Act Safety Radiotelephony Certificate. Attending USCG Marine Inspectors found the vessel's Safety Radiotelephony Certificate had expired on 08/10/2021.

Each vessel must carry a certificate with a valid endorsement while subject to the Bridge-to-Bridge Act. Attending USCG Marine Inspectors found the vessel's Bridge-to-Bridge certificate had expired on 08/10/2021.

While transiting, one of the engines stopped producing forwward propulsion and began reversing. The captian un-synced the Voith engines and re-synced which resulted in a return of normal operation. See narrative for additional details.

I Beams (Transverse deck frames) held in place by impropper/unsatisfactory hardware.

B II/40B past due on hydro date. Corrected on the spot. New BII/40B placed in service.

Two (2) Engine room generators jacket water high temperature shut down sensors are “dropping” temperature type and do not reliably activate as temperature rises. Also sensor installation to be moved to top of engine block.

EDG jacket water high temperature shut down sensors are “dropping” temperature type and do not reliably activate as temperature rises. Also sensor installation to be moved to top of engine block.

Emergency fire pump discharge T spool pin hole leak – verify that temporary weld patch is tight under working pressure. Outstanding to replace the spool

Modifications were made to existing PA system during previous shipyard period w/o plan approval or Coast Guard oversight. Submit plans for approval, and upon receipt of approved plans, make vessel available for inspection to the satisfacton of the attending MI. (By next dry-dock and NLT 01JAN2018)

Modifications were made to existing lube oil piping system during previous shipyard period by adding a lube oil preheater for both MDEs w/o plan approval or CG oversight. Submit plans for approval, and upon receipt of approved plans, make vessel available for inspection to the satisfactoin of the attending MI. (By next dry-dock and NLT 01JAN2018)

Modifications were made to existing bathroom arrangements in salon area during previous shipyard period by removing existing male and female bathrooms and installing multiple individual bathrooms w/o plan approval or CG oversight. Submit plans for approval, and upon receipt of approved plans, make vsl available for inspection to the satisfaction of the attending MI.(By next dry-dock & NLT 01JAN18)

2 existing pilothouse AC units were replaced with larger units and an additional AC unit was installed for the crew lounge w/o plan approval or CG oversight. Submit plans for approval (to include at a minimum an updated load analysis and 1 line diagram). Upon receipt of approved plans, make vessel available for inspection to Coast Guard. (By next dry-dock and NLT 01JAN18)

835 written to Generator Failure

Vessel had a loss of power on the #2 SSDG while at the galveston landing. See narratvie for futher details.

EGR automatic vent closure device "louvers" did not properly close during emergency generator shut down test or CO2 discharge test.

EGR CO2 system discharge control head failed pressure test (9.5psi, should read 6 psi). Control head was replaced and tested satisfactory, def corrected on the spot.

Electrical wires entering the side of the metal outlet box on control console are not protected from chaffing. Add stuffing tube or provide chaffing protection.

Port and Starboard navigation lights on either end of ferry have been improperly installed and are not providing proper arc of visibility or illumination.

Child life jacket donning instructions missing.

Make proper repair to navigation light screens.

Emergency fire pump was found to have a pin hole leak. Three other repairs to the suction line had previously been made. Vessel is to replace emergency fire pump suction line from strainer flange to fire pump flange to the satisfaction of attending CG Marine Inspector.

Need to install IMO stickers IAW Fire Safety Plan prior to next quarterly inspection.

Need to install emergency generator space door by next credit dry dock exam.

Prove proper operation of public address speaker in salon and crew's lounge iaw 46CFR113.25. Provide additional deck hand as roving watch until repairs are complete.

Repair or renew 3 broken cable penetrations "pipe nipples" in way of main deck "B" end iaw 46CFR59.90-10

There are 2 fixed CO2 system hoses that are aged and cracking. Replace hoses by 10OCT2011

Missing spare breaker switches in Power Panel #1 in Emergency Gen Room

Verify proper operation of alarm panel indications on bridge including WTD & Bilge Alarms

Repair/Replace E/R tachometer on MDE "A"

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

Complete repairs to and prove proper operation of the #1 SSDG to the satisfaction of the attending CG inspector.

Properly label lifejacket storage contaniers

Repair and show proper operation of "B" end left side radar screen.

Line on ring buoy on starboard forward is worn. Replace line on ring buoy prior to 10 Jan 2010.

Alarm panels on both bridges would not operate. repair alarm panels on both bridges prior to getting underway.

Red over red "Not Under Command" lights did not operate and were not on board. A permanent arrangement and proper operation proven prior to getting underway.

Hinge on port aft life jacket locker was broken.

Main engine bed near aft mount has a cracked weld. Research about metal and proper welding procedures are required to make permanent repair.

REPAIR OR RENEW BROKEN LIGHT FIXTURE ON THE OUTER DECK ON SALOON LEVEL

Repair inoperable engine room exhaust fan.

Complete repairs to lifejacket locker door hinges.

Repair or renew both deteriorated engine room watertight doors.

Ferry grounded over sand bar while operating. Operator is to have diver survey hull and fax over report.

Repair or renew CO2 discharge time delay controls on both the engine room and emergency generator room CO2 systems. Both discharged over 5 seconds early

repair or renew inoperable latch and adjust for proper closure, both saloon fire doors from stairway to main deck.

Prior to operation, replace/renew fire main and overboard discharger.

Prior to operation, provide attestation of low lube alarm.

Prove proper operation of first side speaker from 'A' end on anchor side of vessel.

Provide cover for blank in breaker panel on bridge ('B' end of vessel).

Complete permanent repairs to deck plating IWO both ramp areas as required by CG inspector and ABS surveyor detailed in ABS survey dated 11FEB05. Or subsequent report.

Complete proper repairs to all cracks in deck plating in way of both ramp areas as identified by the Coast Guard Inspectors. Complete repairs to the satisfaction of the attending Coast Guard Inspector. 46CFR71.40

During MAR 05 Dty Dock Renew severely worn deck plating under both ramps and conduct thickness gauging and renew as necessary plating in way of both "aprons".

Vessel operator failed to notify the local Officer in Charge Marine Inspection prior to conducting repairs to damage in violation of 46CFR71.55

Crop frayed anchor cable back five feet from end. Properly re-swedge anchor thimble. Item to be completed to the satisfaction of attending C.G. inspector.

Prove proper operation of Voith-Schneider propulsion system on Bolivar (A) End to the satisfaction of attending CG Marine Inspector.

Prove proper operation of the main generator B low lube oil alarm and shutdown while on shore power.

Replace/Mark emergency escape on 'A' end.

secure electrical wiring on "A" end pitch indicator in voith room.

Tighten/rework watertight door on 'A' end hydraulic compartment.

Rework/Prove weather-tight seal on engine room entrance door "B" end.

Secure leaks on # 1 & 2 SSG's priming gear.

Clean off paint on air receivers and relief valves manufacturer's name plate.

Replace relief valves on #'s 1 & 2 fire pumps with acceptable relief valves.

[name withheld] in way of engine room entrance with vessels name.

Make bilge alarm in 'A' end lube oil compartment accessible, prove proper operation of alarm.

Dog all handles on machinery equipment access door.

Clean or renew markings on below deck watertight door.

Eliminate leak on # 1 fire pump relief valve discharge piping.

Prove proper operation of main fire pump relief valve.

Prove proper operation of pilot house "B" bilge high level alarm panel.

Secure active leaks in engine room in way of fuel leak at fuel filter, Number One Main Engine outboard side and lube oil leak at Number One Main Engine.

Prove proper operation of battery installation exhaust blower and alarm.

PRIOR TO CARRYING PASSENGERS, DEMONSTRATE PROPER OPERATION OF BOTH MAIN ENGINES & ALL ASSOCIATED ALARMS & SHUTDOWNS.

PRIOR TO CARRYING PASSENGERS, REPAIR & DEMONSTRATE PROPER OPERATION OF_x001C_ BILGE ALARM #3A.

REPLACE NON WORKING BULBS IN WATER TIGHT DOOR POSITION INDICATOR PANELS IN "A" & "B" END PILOT HOUSES.

FREE UP MANUAL SWIVEL HANDLE ON "B" END RESCUE BOAT DAVIT.

Free up and demonstrate proper operation of all main deck fire dampers and vent closures.

SPREAD ARMS ON ON "A" END RESCUE BOAT DAVIT CONNECTIONS.

CONNECT WASH BASIN DRAINS IN WOMEN'S HEAD.

DEMONSTRATE PROPER OPERATION OF "B" END STARBOARD RADAR.

PROVIDE DOGGING WRENCH FOR STACK WTDS, FREE UP BOTTOM FOWARD DOG ON P/S DOOR, DEMONSTRATE PROPER SEAL.

PLACE LIGHT FIXTURE IN 85 COUNT PFD STOWAGE LOCKER ON EMERGENCY CRCUIT, MARK AS EMERGENCY LIGHT & DEMONSTRATE OPERATION ON EMERGENCY CIRCUIT.

PROPERLY SECURE ARMORED SHEATHED ELECTRICAL WIRING ON "B" END STARBOARD SIDE ALONG GUNNEL.

REPAIR "B" END SHORE POWER CABLE BOX HINGED COVER.

LABEL FORE & AFT VOIT SPACE EMERGENCY ESCAPES "EMERGENCY ESCAPE - KEEP CLEAR".

PROVIDE MEANS FOR MAKING PROPER SEAL OF FORWARD ENGINE ROOM WTD WITH PERSONNEL ENTRY BARRIER BAR IN DOWN POSITION.

PRIOR TO CARRYING PASSENGERS, PLACE ON BOARD "T" HANDLE FOR OPERATING FUEL TANK REMOTE SHUT OFF VALVES.

PRIOR TO CARRYING PASSENGERS, PLACE ON BOARD AND RECONNECT ANCHOR TO ANCHORLINE.

MAKE PERMANENT REPAIRS TO LEAKING BLADE SEAL TO THE SATISFACTION OF THE COGNIZANT [name withheld] PASSENGERS, AND NO LATER THAN 31 MARCH 2000.

Crop and renew seachest vent pipe to good metal.

INSTALL REMOTE FUEL SHUTDOWN.

ADJUST AND DEMONSTRATE PROPER OPERATION OF VOITH DRIVE ZERO PITCH LIMIT SWITCHES.

INSTALL AND DEMONSTRATE PROPER OPERATION OF LUBE OIL SHUTDOWN MECHANISM ON BOTH MAIN DRIVE ENGINES.

ADJUST AND PROVE PROPER OPERATION OF #1 AND #2 S/S GENERATOR OVERSPEEDS.

PROVIDE OPERATING INSTRUCTIONS AT BOTH FIXED FIRE SUPPRESSION SYSTEM LOCAL LOCATIONS.

PROVIDE A RESCUE BOAT WITH MOTOR OF ADEQUATE HORSEPOWER IAW 46 CFR 199.630 (h)(2)(i).

FREE UP EMERGENCY EXIT IN BOTH EMERG STEERING ROOMS.

ADJUST WATERTIGHT DOORS TO PROVE WATERTIGHT INTEGRITY BY CHALK TEST.

DISPLAY EMERGENCY STEERING INSTRUCTIONS IN BOTH AFTER STEERING ROOMS.

REPLACE OAR LOCKS IN BOTH RESCUE BOATS.

REPLACE BAD SECTION OF BILGE LINE NEAR FUEL OIL DAY TANK - GALVESTON END OFENGINE ROOM.

PROVIDE STEPS TO EMERGENCY EXIT IN AFT STEERING ROOM - BOLIVER END.

LABEL EMERGENCY LIGHTS WITH E WHERE APPLICABLE.

PROVE PROPER OPERATION OF HIGH TEMPERATURE ALARM SETTINGS (OIL/WATER) ON BOTH S/S GENERATORS.

PROVE PROPER OPERATION OF THE LOW LUBE OIL SHUT-DOWN SET POINT ON BOTH S/S GENERATORS.

PROVIDE MECHANICAL FORCED VENTILATION IN EMERGENCY GENERATOR ROOM IAW 46 CFR 111.15-10 (d)(1).

PROVIDE PROPER MEANS OF ESCAPE FROM EMERGENCY GENERATOR ROOM DOOR IAW MSM VOL. II, CHAPT. 18.5.c.

PROVE PROPER OPERATIONS OF LOW LUBE OIL ALARMS AND SHUT-DOWNS ON MDEs, EMERGENCY GENERATOR and S/S GENERATORS.

PROVE PROPER OPERATIONS OF HI TEMPERATURE ALARMS ON MDEs, EMERGENCY GENERATOR AND S/S GENERATORS.

REMOVE BRASS PETCOCKS FROM ALL FUEL OIL FILTERS AND FIT WITH STEEL PLUGS ORPETCOCKS.

PROVE PROPER OPERATION OF LOW HYDRAULIC LEVEL ALARM TO VOITH UNITS LOCATED IN BOTH WHEELHOUSES.

PROVE PROPER OPERATION OF WATERTIGHT DOOR OPEN/CLOSE INDICATOR LIGHTS ON BOLIVAR SIDE WHEELHOUSE (#! & #8 DOOR LIGHTS OOC).

MAKE REPAIRS TO ENGINE ROOM AND EMERGENCY GENERATOR HALON SYSTEM TO THE APPROVED DRAWING.

PRIOR TO CARRY OF PASSENGERS CONDUCT FIRE AND BOAT TEST IN PRESENCE OF COG.OCMI

POST VSL STAB LTR PRIOR TO PASS. CARRIAGE

PERM. MOUNT WHEEL HOUSE COMPASS.

PROVIDE NAME PLATE DATA FOR BOTH RESCUE BOATS OR REPLACE WITH APPROVED RESCUE BOATS.
