HENRY HUDSON

REQUIRED E/R OVERHEAD INSULATION IS DAMAGED, NOT INTACT IN MULTIPLE LOCATIONS (NOT LIMITED TO BAR DRAIN, PORT PIPE PENETRATIONS, ETC.) REPAIR / REPLACE REQUIRED SFP INSULATION TO [name withheld].

LAZARETTE TRANSVERSE FRAME (2ND FWD OF TRANSOM) CRACKED, BUCKLED DUE TO STRESSES / FORCES. REQUIRES PROPER STRUCTURAL REPAIR. SUBMIT REPAIR PROPOSAL FOR [name withheld]. PRIOR TO REPAIRS, THEN PERFORM REPAIRS PER APPROVED PLAN TO [name withheld] / TESTING.

CFR / EPA TWO, BOTH, SEWAGE TANKS IN LAZARETTE WERE OBSERVED WITH SUBSTANTIAL PITTING, TEMPORARY EPOXY REPAIRS, AND ACTIVE LEAK ON FWD TANK. SUBMIT PROPOSAL FOR REPAIR / REPLACEMENT TO OCMI FOR REVIEW & APPROVAL.

ANCHOR CHAIN (STBD) OBSERVED WITH SIGNIFICANT CORROSION / WASTAGE COMPROMISING STRENGTH. REPLACE WITH SUITABLE GRADE, MATERIAL, SIZE ANCHOR CHAIN.

GEN-SET GAUGES AT OPERATING STATION NOT OPERABLE. EXCESS NOT REQUIRED, BUT MUST OPERATE AS DESIGNED / INTENDED IF INSTALLED. REPAIR OR REMOVE IF REMOVAL DOES NOT COMPROMISE SAFETY.

NAVIGATION LIGHTS ON INSPECTED VSLS OVER 65FT MUST BE UL1104 RATED OR OTHERWISE USCG APPROVED / ACCEPTED. REPLACE NAV LTS WITH PROPER / TESTED LIGHTS OR PROVE VALIDITY VIA PART NO. / SPECS.

2ND DECK PLEXI-GLASS WINDOWS CRACKED AND UNFASTENED IN MULTIPLE PLACES. AND OBSTRUCT VISIBILITY OF OPERATOR IN PORT / STBD AFT DIRECTION. REPAIR / REPLACE OR REMOVE TO [name withheld].

DRAFT MARKS ARE REQURIED TO ENSURE PROPER LOADING OF VSL. IAW STABILITY LTR. DRAFT MARKS NOT VISIBLE, PROVIDE / RESTORE AS REQUIRED.

PORT AIR RECEIVER (START AIR & AIR THROTTLES) UNABLE TO VERIFY SET PT. / OPERATION OF PRD. PROVIDE EVIDENCE OF PROPER SIZING, PSI RELEASE SET PT. TO [name withheld].

E/R FIRE DETECTION DID NOT OPERATE ON INSTALLED / INTERNAL BACK-UP BATTERY SOURCE AS DESIGNED. REPAIR TO [name withheld] OR PROVIDE OCMI WITH REPLACEMENT PROPOSAL OF TYPE APPROVED SYSTEM.

[withheld — contains personal information; the deficiency system, dates, and resolution status are shown above]

MI observed several unfastened windows on upper deck. Repair/fasten down prior to credit dry dock.

Propulsion machinery must be suitable in type and design for propulsion requirements of the hull in which it is installed and capable of operating at a constant marine load. Vessel report a loss of propulsion due to port side engine being rendered inoperable causing an undue risk to the port of New York. In order to clear this deficiency the following actions must be carried out: 1. Provide a causal analysis report on the loss of propulsion and provide a repair proposal. 2. Post-approval of repair proposal and upon completion of repairs, provide USCG a tech report delineating all repairs and pier side propulsion test satisfactory. 4. Vessel must undergo an underway sea trial to the satisfaction of an attending marine inspector prior to carrying passengers.

All Pressure vessels must meet the requirements of sub-chapter F. Port air receiver failed hydrostatic test. 46CFR119.330 701C

Where liquid level indicating gages are installed, they shall be provided at the tank connections with devices which will automatically close in the event of rupture of the gage or gage lines. MI observed the liquid level indicator does not automatically close. Cite: 46CFR182.20-25(a)(5)

All electrical installations shall be to the satisfaction of the Officer in Charge, Marine Inspection. MI observed alternator was arking and sparking. Vessel must replace alternator. Cite: 46CFR183.01-15(a)

Penetrations for hydraulic steering lines, port and starboard sides of pilot house, lack complete smoke and flame barrier. Remove compromised filler material and refill penetrations with material certified for A-Class boundaries. 46 OLD CFR 177.10-5

Vessel reported a unintended grounding causing a Marine Casualty. IAW 46 CFR 122.304 the movement of the vessel shall be under the direction and control if the master at all times and shall operate the vessel keeping the safety of the passengers and crew. Vessel must be pulled out of water for damage survey. Make proper repairs to damaged areas and complete successful sea trials to the satisfaction of a USCG Marine Inspector prior to carrying passengers for hire. 46 CFR 115.700(a)

At each inspection all observed unsafe practices, fire hazards and other hazardous situation be corrected. Overhead light and expansion tank for starboard generator were zip ties to piping in engine room. Mount light and expansion to correctly. 46 CFR 115.840 (a)

A storage cylinder must be securely fastened, supported, and protected against damage. CO2 bottle for fixed firefighting system was loose and not secured properly. Secured CO2 bottle correctly. 46 CFR 118.410(c)(4)

At each inspection all observed unsafe practices, fire hazards and other hazardous situation be corrected. Water intrusion was seen coming from upper deck into main deck. Locate source of water intrusion and make repairs. 46 CFR 115.840(a)

Each life jacket must be marked in clearly legible black letters with vessels name. 04 Child life jackets and 02 adult life jackets were missing vessels name. Add vessels name to life jackets. 46 CFR 122.604(b)

Each connection to a conductor or terminal part of a conductor must be made within an enclosure. Outlet in engine was missing enclosure. Provide enclosure for outlet. 46 CFR 120.340(g)

At each inspection the bilges and other spaces maybe examined to see that there are no excessive accumulation of oil, trash, or debris that might create a fire hazard. Oil was in engine room and diesel was fuel tank void bilges. Remove all oil and diesel from bilges. 46 CFR 115.830(b)

A-Class bulkheads or decks must be composed of steel or equivalent material and must be so insulated with approved structural insulation. Insulation of missing in overhead forward starboard side of engine room. Replace missing insulation. 46 CFR 116.415 (2)(i)

An exposed hazard, such as gears or rotating machinery, must be protected by a cover, guard or rail. Rotating flex coupler of port and Starboard MDE's were missing a guard. Provide guards for rotating machinery. 46 CFR 116.960

Make proper repairs/replace both the port and starboard props.

Make proper repairs/replace the port and starboard shaft struts.

Make proper repairs/replace starboard shaft. Operator shaft will be replaced.

Crop and renew bottom plate aft of starboard rudder. Cracked hull due to rudder breaking the hull from grounding.

Replace cracked top bearings/shaft collars on both the port and starboard rudder assembilies.

Crop and renew 2 areas on transverse frame connecting between the port and starboard rudder assemblies.

At each inspection for certification and each other inspection the bilges and other spaces may be examined to see that there is no excessive accumulation of oil, trash or debris the might create fire hazards or blockages. Attending Marine Inspector (MI) found approximately 6" of blue tinted water in the lazarette space. Vessel not operating in compliance with the COI. 46CFR115.830(b) 46CFR115.100(b)

At each inspection for certification and each other inspection the bilges and other spaces may be examined to see that there is no excessive accumulation of oil, trash or debris the might create fire hazards or blockages. Attending MI found 6" of oily water in the engine room bilge. Vessel not operating in compliance with the COI. 46 CFR 115.830(b) 46 CFR 115.100(b)

The design of all exhaust systems must ensure minimum risk of injury to personnel and protection must be provided in compliance with 46CFR116.970. Attending MI found missing and loose exhaust lagging in engine room. 46 CFR 182.20-20(a)

A vessel is inspected for compliance with the standards required by this subchapter, however items not covered are inspected in accordance with OCMI as good marine practice. Attending MI determined the electrical conduit was not properly supported and the junction boxes were missing covers in the overhead. 46 CFR 115.800(a)

At each inspection for certification and each other inspection the bilges and other spaces may be examined to see that there is no excessive accumulation of oil, trash or debris the might create fire hazards or blockages. Attending MI found approximately 50 gallons of coolant in the fuel tank space bilge. Vessel not operating in compliance with the COI. 46CFR115.830(b) 46CFR115.100(b)

Receptacle outlets and attachment plugs for portable apparatus operating at 100 volts or more must have a grounding pole and grounding conductor in the portable cord. Attending MI found a portable electric heater that had the ground conductor removed from the plug. 46CFR183.10-20(o)

This vessel is a "TL-boat", therefore not required a safety management system (SMS) per regulation. Sector NY has found the following deficiencies to be objective evidence that a serious substandard condition has not been pro-actively managed by the vessel's owner/operator, leading to a lack of safety culture onboard the vessel. 46CFR176.25-50

Generators and engines do not shutdown as required upon activation of installed fire protection system.

Bilge alarm float switch does not function properly.

Stbd aft electrical panel on bridge has a large loose wire. Remove or place in enclosure.

Post emergency broadcast placard at operating station.

Remove and clean all PFD's and their storage areas. Label all PFD's with vessel name.

Update PFD storage placards throughout vessel. Anywhere PFD's are stored must be labeled "Adult/Child Life Jackets"

Repair exhaust rips/missing in lazarette space.

STARBOARD MAIN ENGINE AND GENERATOR EXHAUST CONNECTION TO HULL IS FAILING. MAKE WATERTIGHT.

Replace or repair structural fire protection portside enigine room frames #2, #3, and #4 (overhead only) to satisfaction of attending CGMI.

Replace frayed wired on portisde main diesel engine.

Replace inspection port covers of magnetic pickups on both main diesel engines.

Provide repair proposal for broken glass on forrward sliding glass doors.

Conduct smoke detector test in engine room.

Vessel lost throttle and gear control after port generator went offline and air tanks could not be replenished. Make satisfactory repairs to port generator and demonstrate satisfactory operation of vessel controls via sea trials.

Flex coupler on port MDE was reported as defective. Must repair in kind and demonstrate satisfactory sea trials.

Provide permanent rudder stop for rudder in laz.

Provide current FCC Safety Radio Certificate . Vessel is restricted to operations no more than 1000 feet from shore until a valid certificate is issued and placed onboard.

Provide current FCC Bridge to Bridge Radiotelephony Certificate. Vessel is restricted to operations no more than 1000 feet from shore until a valid FCC Bridge to Bridge Radiotelephony Certificate is issued and placed onboard.

Provide servicing for all portable fire extinguishers and the fixed gas fire extinguishing system on board prior to carrying passengers.

Crop and renew holed section of the side shell, on the starboard side, transom IWO the corner post.

Replace wasted flex hose servicing the transmission oil cooling system IWO the Port MDE.

Grind and reweld the following cracks: Five (05) total welds on vertical stiffeners IWO the forepeak, Four (04) bottom welds IWO the Forepeak and one (01) top weld IWO the forepeak.

Grind and reweld one (01) cracked weld in 2nd bay, 3rd frame from the top, 3rd bay.

Visibly mark aft stairwell for a maximum of 200 passengers as per the stability letter dated December 22, 1992.

Grind out /weld rough edges IWO bow keel as discussed (approximate 1ft).

Clean out debris IWO screen plates Fire/bilge pump sea suction.

C/R aft stbd side rub rail corner.

Refasten rubber bumper retaining bolt (fwd main deck).

Replace bubbled stbd steering hydraulic hose (IWO stbd steering feed line).

Remove unused (old) anchor windlass. After removal restow anchor as required.

There is a tear through the hull plating on the starboard side aft corner. There are doubler plates and epoxy covering the tear at the 2nd transverse frame below the deck on the hull interior in the lazarette. Make permanent and proper repair prior to carrying passengers.

There is a cracked weld at the starboard hull Sampson post bracket, located in lazarette. Make permanent and proper repair prior to carrying passengers.

There is an inset on the starboard aft corner between deck and first transverse frame (in lazarette). Make permanent and proper repair prior to carrying passengers.

The HALON 1301 cylinder for the engine space fixed fire extinguishing system is low on pressure and gauge needle is positioned in "recharge" zone. Have HALON 1301 cylinder and fixed system serviced prior to carrying passengers.

Both air receivers located in the engine space are overdue for inspection (MAY 2007). Test and inspect both air receivers in the presence of USCG Marine Inspector prior to carrying passengers.

Provide repair proposal for items DB01, DB02, and DB03 for approval prior to making repairs.

Remove anti-freeze that has leaked into forepeak bilge and determine source of leak and repair.

Remove or properly enclose dead end wire located in cabinet in wheelhouse in vicinity of fixed fire system alarm panel.

Replace broken/damaged fire extinguisher bracket in wheelhouse.

Provide valid fixed firefighting system.

Properly terminate dead end wires underneath bridge console (port side)

Repair cracked welds on fwd deck rail (port side) as marked.

V/W cracked weld on longitudinal (port side) aft bay overhead IWO steering gear.

V/W cracked weld on longitudinal (port side) IWO rudder post (overhead) area is marked.

V/W 02 cracked welds on longitudinal (port side) overhead IWO #2 bay fwd.

V/W cracked welds on long port and stbd side bay #1 overhead. Areas are marked.

Provide cover for junction box stbd side MDE (outboard)

Remove dead end wires off stbd MDE outboard.

Replace cracked/chafed hose on stbd MDE. (fuel hose) as marked.

Determine source of leak on stbd MDE and make proper repairs.

Replace cracked windows starboard side aft (2nd window from stern) and port side aft IWO of stair.

V/W cracked stanchion on stern IWO cleat.

Repair leak in sullage tank as discussed with rep and clean bilge.

Replace lanyard on lifering buoy aft deck. (Lanyard is currently wire cable)

Replace phone and provide cover for phone box on top aft deck.

Replace non-conductive mat IWO generator switchboard.

Replace hydraulic steering tube bracket.

Replace float - switch on Marine Sanitation Device as per 33 CFR 159.95.

Provide CG approval sticker for two fire extinguishers as per 46 CFR 115.800.

Remove debris/oily mixture from engine room bilges as per 46 CFR 115.830.

Properly remove/terminate exposed dead - end wires stbd. quarter deck.

Provide updated fire control plan as per 46 CFR 116.530.

Replace BA's w/ Life Floats or remove all BA's.

Make repairs to exhaust leak on stbd main engine. LEGACY COMPONENT DESC: Piping (exhaust)

Make repairs to port main engine exhaust LEGACY COMPONENT DESC: Piping (exhaust)

Make repairs to stbd fuel filter. LEGACY COMPONENT DESC: Distributor (fuel injection)

v/w crack on stbd & port main eng. mounts.

Replace lagging on stbd main engine generator keel cooler

Replace hose iwo port engine mount.

Make repairs to water leak on fire pump.

Make proper repairs to port sounding tubes, fuel leak. LEGACY COMPONENT DESC: Piping

Afix stbd & port main engine exhaust bracket to overhead. LEGACY COMPONENT DESC: Piping (exhaust)

Stencil hailing port on 3 lifering buoys.

Replace damaged window starboard side on main deck accomodation space.

Repair port wheelhouse door and prove proper operation.

Post fire control plan IAW 46CFR116.530.

Prove proper operation of fixed firefighting system. Vessel is restricted from operation until requirement is met.

Prove proper operation of bilge pump system and repair manifold. Vessel is restricted from operating until requirement is met.

Make starboard hatch (2nd deck) watertight.

Replace light switch cover at entrance to engine room.

Make permanent repairs to the cracked hull plating IWO the aft port sideshell and transom. Submit repair proposal to attending USCG Marine Inspector. LEGACY COMPONENT DESC: Hull Plating

Repair or remove bow light port side. LEGACY COMPONENT DESC: Lighting Fixture

Reposition lifejacket donning placard upper deck forward to make readable to crew/passengers. LEGACY COMPONENT DESC: Marking

Tighten union to stop leakage of fuel from stick line in tank room. LEGACY COMPONENT DESC: Flange

Post hearing conservation placard at entrance to engine room. LEGACY COMPONENT DESC: Guards for Exposed Hazards

Replace guard on engine room light at stairwell. LEGACY COMPONENT DESC: Lighting Fixture

Remove, reconnect or insulate dead-ended wiring on engine room blower motor. LEGACY COMPONENT DESC: Wiring

Label emergency escape in engine room. LEGACY COMPONENT DESC: Emergency Preparedness

Submit repair proposal for deck insert beneath galley sink.

Conduct hydrostatic test or internal exam of two air receivers in presence of USCG marine inspector. LEGACY COMPONENT DESC: Receiver/Bottle

Provide door for pilothouse 230/110 AC distribution panel. LEGACY COMPONENT DESC: Panelboard

Remove dead-ended wiring, replace improper wiring for horn, properly terminate "spare" wiring, and remove automotive "piercing splice" connectors from under port and stbd sides of operators console. LEGACY COMPONENT DESC: Wiring

Replace sea painter lines (yellow) to stbd Buoyant Apparatus with UV resistant or black line. LEGACY COMPONENT DESC: Sea painter

Repair minor fuel leak in couplings in fuel tank void at tanks and on port side outboard. LEGACY COMPONENT DESC: Piping

Repair oil leak in valve above oil transfer pump. LEGACY COMPONENT DESC: Valve

Replace structural fire protection insulation where missing in engine room in way on escape hatch to main deck. LEGACY COMPONENT DESC: Decks - Accommodation Spaces

Provide a flame impingement bowl for the stbd generator RACOR fuel filter. LEGACY COMPONENT DESC: Filter/Strainer

Provide roof of servicing Halon Bottle/repair of gauge. LEGACY COMPONENT DESC: Quantity of Halon

Make temporary repairs to leaks in bottom plating of lazaret to the satisfaction of the attending Marine Inspector.

Drydock and make permanent repairs to lazaret bottom plating.

Renew the 2-12 volt batteries for the Fire Detection System (second source of power in a vital system).

Provide the manufacturer's instruction manual for maintenance and testing of the FIRELARM Fire Detection System.

COMPLETE AS BUILT VERIFICATION FOR STRUT MODIFICATIONS IAW NYCMI EXAMINED PLANS, AND NYCMI LTR PR-010039.

Void 1, bay 1 - v/w framing IWO SS and overhead

Repair/replace nonmetallic piping for main engine ventillation

Prove proper operation of LAZ bilge alarm.

Prove proper operation of engineroom ventillation dampers.

Provide servicing report for Halon Tank

Prove operation of emergency fuel oil tank valve prior to carrying passengers.

Provide light for magnetic compass

CLEAN AND DE-GREASE ENGINE VENT, FIRE DAMPER AND MOTOR.

MAKE PERMANENT AND PROPER REPAIRS TO HYDRAULIC LINES TO STEERING SYSTEM IN THE LAZZARETTE.

C/R RUB RAIL AS MARKED.

REPLACE VALVE ON KEEL COOLING SYSTEM IN ENG ROOM._x001C_ (OUT FOR REPAIR)

MAKE PERMANENT AND PROPER REPAIRS TO THE IMPROPER REPAIR ON THE STBD SIDE BAY# IN THE FUEL TANK VIOD IWO OF SSL #1 & 32 FROM TOP AS MARKED.

REPLACE OR REMOVE LIGHT ON THE UPPER DECK AND AFT DECK RING BUOY.

REPLACE SEA PAINTERS ON ALL BUOYANT APPARATUS.

REPLACE LINE AND CLIP ON FWD DECK LIFE RING.

SECURE COFFEE MAKER IN SERVICE AREA.

PROVIDE BILGE HIGH LEVEL ALARM AS PER APPROVED PLAN AND IAW WITH 46CFR530.

MAKE PORT AND STARBOARD AIR RECIEVERS AVAILABLE FOR INTERNAL INSPECTION OR HYDRO TEST.

REMOVE OR PROPERLY DEAD END UNUSED WIRES FROM PILOT HOUSE CONSOLE.

PROVIDE AND PROPERLY POST ORIGINAL STABILITY LETTER TO MARINE INSPECTOR.

PROVIDE DEVIATION CARD FOR MAGNETIC COMPASS.

MAKE MAN-OVER-BOARD SOCKETS WEATHER TIGHT TO SATISFACTION OF MARINE INSPECTOR.

PROVIDE AND POST STATION BILL FOR VESSEL.

MARK MAXIMUM PASSENGER CAPACITY FOR UPPER DECK ON FORWARD ACCESS LADDERS.

PROVIDE BLANK FOR CIRCUIT BREAKER PANEL ON BRIDGE.

REPAIR HOLES IN BOUYANT APPARATUS, STBD SIDE FORWARD.

RESTENCIL MAXIMUM PASSENGERS FOR PORT SIDE FORWARD BOUYANT APPARATUS.

PROVE PROPER OPERATION OF EMERGENCY FUEL SHUT OFF VALVE.

PROVIDE EMERGENCY BROADCAST PLACARD

REMOVE FUEL FROM BILGE JUST BELOW FUEL TANK IN # VOID

REPAIR FRESH WATER SUPPLY LINE ABOVE MEN'S HEAD

MAKE OPERABLE WATERLIGHT FOR 3RD B/A ON THE STBD SIDE

REPAIR SEEM ON B/A - FIRST ONE ON THE PORT SIDE.

RE-ATTACH GROUND WIRE ON STBD RUDDER POST

PROVIDE DRAWING G-H DWG NO. P-285-630 TO COGNIZANT OCMI FOR PLAN REVIEW OF ENGINE COOLING SYSTEM. _x001C_ _x001C_ _x001C_

ATTACH ALL BUOYANT APPARATUS INDIVIDUALLY TO PAINTERS. TO BE COMPLETED TO THE SATISFACTION OF ATTENDING MARINE INSPECTOR. _x001C_ _x001C_ _x001C_

REPLACE GASKET ON DISCHARGE FLANGE OF FIRE PUMP. TO BE COMPLETED TO SATISFACTION OF ATTENDING MARINE INSPECTOR. _x001C_ _x001C_ _x001C_

PROPERLY MARK EMERGENCY LIGHTS TO THE SATISFACTION OF ATTENDING MARINE INSPECTOR.

PROVIDE APPROVED PLANS FOR BILGE AND FIRE SYSTEMS._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE APPROVED PLANS FOR VESSEL'S STEERING SYSTEM._x001C_ _x001C_ _x001C_ _x001C_

PROVIDE FCC SHIP STATION LICENSE.

CONDUCT FIRE AND MAN OVERBOARD DRILLS TO THE SATIFACTION OF THE ATTENDING MARINE INSPECTOR.

PROVIDE APPROVED PLANS FOR VESSEL OPERATING SYSTEMS AS FOLLOWS: STEERING SYSTEM; FIRE/BILGE SYSTEM; GENSET AND MAIN ENGINE COOLING; GENSET AND MAIN ENGINE EXHAUST; COMPRESSEDE AIR AND FUEL.
